A rocket is fired vertically upwards. Its height above the launch point is \(h(t)=4.8t^2\), where \(h\) is in metres and \(t\) is the time in seconds from firing.

An observer at A watches the rocket from the same level as the launch point, \(500\text{ m}\) away. Find the rate at which the angle of elevation at A is increasing when the rocket is \(480\text{ m}\) above the launch point.

A500 mh(t)θ

You must use calculus and show any derivatives that you need to find when solving this problem.

Original question scanOriginal scan of the question transcribed above
Hint

First walkthrough idea

Focus to try first

Related rates for an angle of elevation.

First worked step

Step 1

Relate height and elevation angle

Relate the height \(h\) and angle of elevation \(A\).

Show the first step’s working
\[ \tan(A)=\frac{h}{500} \] \[ \sec^2(A)\frac{dA}{dt} = \frac{1}{500}\frac{dh}{dt} \]

Walkthrough overview

What this question practises

This 2020 walkthrough is part of AS91578 — Apply differentiation methods in solving problems.

Method: Related rates for an angle of elevation.

This is Question 2(d) from the 2020 NCEA Level 3 Differentiation paper for AS91578 — Apply differentiation methods in solving problems. Attempt the question independently, then use hints and worked steps to compare your reasoning.
